Aquatech Neo
A quick-drying, single-component, flexible, liquid waterproofing membrane for indoor use.
A quick-drying, single-component, flexible, liquid waterproofing membrane for indoor use.
- For indoor use only
- High elasticity
- Quick-drying
- Good walkability
- Tested as a system with a ‘General Building Inspection Test Certificate’ in accordance with DIN 18534 in water exposure classes W0-I, W1-I, W2-I, together with the tile adhesives Tile 2020, Tile 480 or Tile 250, based on the tests for the issuance of an AbP in accordance with PG-AIV-F and the resulting areas of application, the following exposure classes from ÖNORM B 3407 can be assigned – W1, W2, W3 and W4.
Variations
Choose the perfect solution for your project
Grey
White
Application areas
Choose Aquatech Neo for
- For indoor use only, for creating a seamless waterproof seal on wall and floor surfaces in wet areas (e.g. showers, bathrooms and steam rooms, etc.) against water flowing without pressure directly beneath the ceramic tiling
Discover more
Other solutions you might be interested in
Evaproof Fit
PVC drain with vertical outlet, fitted with a square-shaped waterproof…
PVC drain with vertical outlet, fitted with a square-shaped waterproof membrane flange (50 cm x 50 cm). The drain, available in various diameters (Ø75, Ø90 or Ø110 mm), is compatible with Evaproof waterproof membrane systems.
Evaproof Corner
Thermoformed waterproofing element for sealing external/internal corners. It is used…
Thermoformed waterproofing element for sealing external/internal corners. It is used in conjunction with Evaproof Band, and Evaproof Adhesive (a polyurethane adhesive) must be used for its installation.
Evaproof Band
A flexible, waterproof polyolefin elastic tape produced by extrusion, used…
A flexible, waterproof polyolefin elastic tape produced by extrusion, used in conjunction with Evaproof Adhesive polyurethane adhesive to ensure a continuous waterproofing seal in Evaproof membrane systems and for the treatment of vertical upstands.
Evaproof
A flexible, multi-layered, waterproof polyolefin membrane, designed to prevent cracking…
A flexible, multi-layered, waterproof polyolefin membrane, designed to prevent cracking and separate structures, manufactured by extrusion, with a thickness of 1.25 mm and a weight of 525 g/m², coated on both sides with polyester/polypropylene fibre fabric to ensure better adhesion to the cementitious adhesive.
Corner Tissue Lite
Prefabricated, dimensionally stable corners made of coated polypropylene non-woven fabric,…
Prefabricated, dimensionally stable corners made of coated polypropylene non-woven fabric, transversally extensible and longitudinally stable.
PP Tape Lite
Sealing tape made from coated, transversely stretchable and longitudinally stable…
Sealing tape made from coated, transversely stretchable and longitudinally stable polypropylene non-woven fabric, 120 mm.
Flexistar Rapid
Single component, flexible, fibre-reinforced, cementitious, polymer waterproofing membrane with fast…
Single component, flexible, fibre-reinforced, cementitious, polymer waterproofing membrane with fast hardening.
Aquatech® Rapid
Elastic, single-component, quick-hardening liquid waterproofing membrane in water emulsion for…
Elastic, single-component, quick-hardening liquid waterproofing membrane in water emulsion for exterior and interior waterproofing.
Flexistar
Extra-flexible, single-component, fibre-reinforced cementitious polymer sheath for waterproofing and protecting…
Extra-flexible, single-component, fibre-reinforced cementitious polymer sheath for waterproofing and protecting concrete.
Aquaproof
Fine waterproofing mortar.
Fine waterproofing mortar.
Flex 1K
Single-component, flexible, fibre-reinforced, waterproofing cementitious mortar, which can be reinforced…
Single-component, flexible, fibre-reinforced, waterproofing cementitious mortar, which can be reinforced with fibreglass mesh, for flexible waterproofing and protective smoothing of cementitious substrates.
Flex 2K
Two-component, flexible, fibre-reinforced, waterproofing cementbased mortar, which can be reinforced…
Two-component, flexible, fibre-reinforced, waterproofing cementbased mortar, which can be reinforced with fibreglass mesh, for flexible waterproofing and protective smoothing of cementitious substrates. Good UV resistance, elastic to -20 °C.
Details
Aquatech Neo is a fast-drying, single-component emulsion waterproofing compound based on styrene-acrylic elastomers. The product can be applied with a roller or brush. During drying, an elastic and water-impermeable membrane forms, which is resistant to occasional standing water and can be walked on for inspection and maintenance work. Aquatech Neo is classified according to EN 14891 as a jointless, waterproof sealant for interior use of type DM. When installed, the product meets the requirements for Class E building materials in accordance with DIN EN 13501-1.
Instructions for use
Preparation work prior to application
The substrate must be clean, dry, frost-free, solid, stable, dimensionally stable and free from dust, dirt, oil, grease, release agents and loose particles. It must comply with the applicable national and European technical guidelines, standards and the “generally accepted rules of the trade”.
Product preparation
Always mix Aquatech Neo thoroughly before use. To improve adhesion on absorbent substrates, it is recommended to carry out a pre-treatment using “Aquatech Neo” diluted 1:1 with water, depending on the absorbency of the substrate. Coverage: approx. 150 g/m².
Application instructions
Once the primer is walkable (depending on ambient conditions, the waiting time is between two and ten hours), apply Aquatech Neo in at least two coats using a brush, roller or trowel, applying the coats in a criss-cross pattern. Aquatech Neo must be applied undiluted, i.e. at least 1 kg/m², to achieve a dried layer of approx. 0.5 mm. Each coat must only be applied once the previous coat is walkable. Aquatech Neo is available in two colours, white and grey, to allow the two coats to be distinguished by colour across the entire surface to be treated.
Application example
In accordance with DIN 18534 for wall and floor surfaces in water exposure classes W0-I to W2-I. Ready-to-use, two-colour, fast-drying, solvent-free liquid waterproofing membrane for sealing interior wall and floor surfaces in damp and wet rooms beneath ceramic and natural stone coverings. This includes floor surfaces in bathrooms without floor drains but with shower trays or bathtubs, and wall surfaces in sanitary areas in public and commercial premises with floor drains where there is no exposure to chemicals.
Suitable substrates
Depending on the moisture exposure classes or water exposure classes, suitable substrates include, for example, mineral substrates made of concrete, cement and lime-cement plasters, cement screeds, calcium sulphate screeds (anhydrite and anhydrite self-levelling screeds), and dry screeds.
System description/application
The substrate should be primed using Tile Primer (primer for absorbent substrates) or Multigrip (for non-absorbent and complex substrates). Both products are applied once using a roller or brush. The sealing collars with expansion zone and sealing lip, type Flex Pipe Collar 22-37, 50-75 and 93-146, the sealing tape PP TAPE or PP-Tape Lite 120 MM – made of TPE-coated, transversely stretchable and longitudinally stable polypropylene– fleece 120 mm, the prefabricated special internal and external corners Corner Tissue Corner Tissue or Corner Tissue Lite made from TPE-coated, transversely stretchable and longitudinally stable polypropylene fleece are bonded to the substrate using adhesive Tile 2020, Tile 480 or Tile 250 or Aquatech Neo. The Floor Collar is a TPE film laminated on both sides with PP fleece, which is inserted between the first and second layers of the liquid-applied Aquatech Neo.
Storage
Aquatech Neo has a shelf life of at least 12 months if stored in its original packaging in a cool place (at temperatures between +5 °C and +30 °C). PROTECT FROM MOISTURE:
| Color | Code | Packaging size | Pallet | Barcode |
|---|---|---|---|---|
| Grey | 5761 | 6kg |
64 buckets
|
|
| White | 5759 | 6kg |
64 buckets
|
|
| Grey | 5762 | 15kg |
33 buckets
|
|
| White | 5760 | 15kg |
33 buckets
|
|
- For indoor use only, for creating a seamless waterproof seal on wall and floor surfaces in wet areas (e.g. showers, bathrooms and steam rooms, etc.) against water flowing without pressure directly beneath the ceramic tiling
| PARAMETER | VALUE |
| Operating temperature | +5 °C to +40 °C |
| Operating temperature | -40 °C to +120 °C |
| Density | 1.59 g/ml |
| Viscosity | 61 Pa*s |
| Dry matter | 77% |
| pH | 8 |
| Consistency | paste-like |
| Initial adhesion* (EN 14891 A.6.2 ≥ 0.5 N/mm) | 1.79 N/mm² |
| Adhesive tensile strength after immersion in water* (EN 14891 A.6.4 – ≥ 0.5 N/mm) | 0.8 N/mm² |
| Tensile strength after heat exposure* (EN 14891 A.6.5 – ≥ 0.5 N/mm) | 2.88 N/mm² |
| Tensile strength after freeze-thaw cycles* (EN 14891 A.6.6 – ≥ 0.5 N/mm) | 0.5 N/mm² |
| Adhesive tensile strength after immersion in lime water* (EN 14891 A.6.9 – ≥ 0.5 N/mm) | 1.29 N/mm² |
| Water impermeability (EN 14891 A.7 – no penetration) | no penetration |
| Weight gain (≤ 20 g) | 0.5 g |
| Crack bridging ability under standard conditions (according to EN 14891 A.8.2 – ≥ 0.75 mm) | 7.00 mm |
| Classification according to EN 14891 | DM |
| APPLICATION DATA (at +23 °C – 50% RH) | |
| Coverage | 1 kg/m² for a 0.5 mm layer |
| Drying time between first and second coat | approx. 30 minutes, provided the surface is dry |
| Drying time before the coating can be used | min. 4 hours (varies depending on ambient temperature and humidity) |
The coverage of Aquatech Neo varies between 0.3 and 1.0 kg/m² per coat, depending on the substrate. On porous substrates, it is advisable to apply an initial bonding coat of ‘Aquatech Neo’, diluted 1:1 with water. In this case, the consumption of the undiluted product is 150–200 g/m².
