BW 200
Multi-function bituminous waterproofer.
Variations
Application areas
Discover more
BW 200 is a liquid bituminous water-based elastomeric waterproofing agent containing bitumen, inert fillers, elastomeric resins, additives. Suitable for waterproofing both horizontally and vertically concrete and cement surfaces in general, gypsum, metal and glass, slated membranes or old bituminous coverings to be restored, plaster and plasterboard, wooden roofs, ceramic floors, bathrooms, showers, vases and flower boxes.
Preparation for use
Make sure that detached parts, brittle or non-adherent parts, paint, rust, dust, release agent oils are removed and thoroughly clean surfaces that must be solid and dry. BW 200 can also be applied on slightly damp surfaces. The substrates to be treated must be mature and cured and must not present defects or irregularities that lead to the application of an excessive thickness of product and that compromise regular drying. Waterproofing parts with b.p. membranes must be carried out before installing the membrane (reversing the installation phases must be avoided). Check that there is no rising damp or water counterthrust. Apply at temperatures between +5 °C and +35 °C; avoid extreme hot and cold conditions during application and drying of the film.
Instructions for use
BW 200 can be applied with a roller, brush, spray, long-handled scrubbing brush, masonry trowel or toothed trowel. Application in two coats is recommended. Apply the second coat when the first one is completely dry. On surfaces larger than 10 m², critical points or mechanically stressed substrates we recommend reinforcing BW 200 with suitable Torggler NT50 non-woven polyester reinforcement buried in the first coat while still fresh. Apply BW 200 on new roofs with membranes without mineral finish only after a coat of Torggler Black Hydro Easy diluted to 10%. Wash tools immediately after use with water. After hardening BW 200 should be removed with hot water or thinner.
Store BW 200 in a dry and sheltered place in the original packaging. Do not expose the packages to temperatures below +5 °C. It will keep for at least 12 months. PROTECT FROM FROST.
Avoid applying BW 200 on surfaces subject to water stagnation.
Do not apply on very hot substrates that would cause negative consequences on the cohesion and adhesion of the product to the substrate.
In case of application on polymer bitumen membranes or bituminous coverings, check the adhesion of BW 200 before proceeding with the application.
It is important that the application takes place at an ambient temperature between +5 °C and +35 °C. Extreme hot and cold conditions and adverse weather conditions should be avoided during application. The still wet layer can be washed away by rainwater or ruined by dew and frost.
BW 200 may be walked on occasionally in cases of occasional maintenance.
| Color | Code | Packaging | Packaging size | Pallet | Barcode |
|---|---|---|---|---|---|
| Black | 8123 | bucket | 5 kg |
80 buckets
|
|
| White | 8387 | bucket | 5 kg |
80 buckets
|
|
| Grey | 8388 | bucket | 20kg |
33 buckets
|
|
| White | 8386 | bucket | 20kg |
33 buckets
|
|
| Red | 8390 | bucket | 20kg |
33 buckets
|
|
| Terracotta | 8391 | bucket | 20kg |
33 buckets
|
|
| Green | 8392 | bucket | 20kg |
33 buckets
|
|
| Grey | 8389 | bucket | 5 kg |
80 buckets
|
|
| Black | 8067 | bucket | 20kg |
33 buckets
|
BW 200 is suitable for waterproofing and protecting, both vertically and horizontally:
BW 200 can be used as a primer coat for the laying of:
In addition, BW 200 diluted to 50% can be used as a dust proof primer when bonding insulation panels to porous substrates.
* NOTE: Connect the b.p. membranes with other elements only on slated membranes.
| Appearance | Liquid |
| Colour | Grey |
| Colour after drying: | Black |
| Flash point when the vessel is closed | Non-flammable |
| Dry residue at 130 °C (EN ISO 3251) | 66-74% |
| Viscosity (Brookfield 20 °C gir. No. 5-10 rpm) (EN ISO 3219): | 30.000 cp ± 600 |
| Specific weight at 20 °C (EN ISO 2811-1): | 1.35 kg/l ± 0.05 |
| pH | 7-8 (at 20 °C) |
| Adhesion for direct traction on wood/metal (EN 1542:2000) | 1.7 N/mm2 |
| Touch dry time (*) | 6 hours |
| Covering drying time | 24/48 hours |
| Average consumption with two coats without reinforcement | 1.5-2.0 kg/m2 |
| Average consumption with two coats with reinforcement | 2.0-2.5 kg/m2 |
(*) Values recorded at 23 °C and 50% R.H. The data may vary depending on the thickness of the product applied and the specific site conditions: temperature, humidity, ventilation, absorbency of the substrate.
| Performance characteristics EN 1504-2:2004 – Coatings – PI MC IR | |
| Permeability to CO2 | SD >50 m |
| Permeability to water vapour | Class I |
| Capillary absorption and permeability to water | w <0.1 kg/(m2h0,5) |
| Adherence force for direct traction | >1.0 N/mm2 |
| Abrasion resistance | <3 g |
| Impact resistance | Class II |
| Performance characteristics EN 14891:2002 – MD | |
| Initial tensile strength | ≥ 0.5 N/mm2 |
| Tensile strength after immersion in water | ≥ 0.5 N/mm2 |
| Tensile strength after exposure to heat | ≥ 0.5 N/mm2 |
| Tensile strength after freeze-thaw cycles | ≥ 0.5 N/mm2 |
| Tensile strength after immersion in lime water | ≥ 0.5 N/mm2 |
| Waterproofness | No penetration |
| Overhead capability under standard conditions | ≥ 0,75 mm |
The consumption of BW 200 varies depending on the substrate and the desired thickness. Average product consumption with 2 coats without reinforcement approx. 1.5-2 kg/m², with reinforcement approx. 2-2.5 kg/m².
Contact our team for personalized support and product guidance.
