Bitumen Seal
Bituminous adhesive-sealant for bonding and repairing membranes.
Bituminous adhesive-sealant for bonding and repairing membranes.
- Ready to use and easy to apply cold
- High elasticity and resistance
- Immediate waterproofing
- Excellent adhesion and fast drying on various substrates
- Good adhesion even on damp surfaces
- High resistance to atmospheric agents and UV rays
- Excellent performance at high and low temperatures
Discover more
Other solutions you might be interested in
Mirror
Neutral silicone adhesive for bonding mirrors.
Neutral silicone adhesive for bonding mirrors.
Sitol® Primer Glass
Primer formulated as a black pre-treatment for glass surfaces to…
Primer formulated as a black pre-treatment for glass surfaces to provide a protective coating against UV radiation.
Sitol® Deck Bonding LV
Low viscosity hybrid adhesive for bonding natural and synthetic teak…
Low viscosity hybrid adhesive for bonding natural and synthetic teak decks. Suitable for large surfaces.
Sitol® M.E.D.
A high-performance structural adhesive and hybrid sealant for all types…
A high-performance structural adhesive and hybrid sealant for all types of applications in the marine industry specifically formulated for bonding and sealing mineral and organic glass.
Sitol® Meta 45
A two-component, methacrylate-based structural adhesive with excellent thixotropic properties that…
A two-component, methacrylate-based structural adhesive with excellent thixotropic properties that enable the creation of vertical lines without dripping and medium curing time.
Adhesive for EPDM membrane
Excellent adhesion to materials such as acrylic glass, steel, stone,…
Excellent adhesion to materials such as acrylic glass, steel, stone, concrete, lightweight concrete, lead and wood.
Sitol® Infinity
Fast curing hybrid adhesive and sealant suitable for wet surfaces.
Fast curing hybrid adhesive and sealant suitable for wet surfaces.
Sitol® Primer Deck Caulking
Primer for sealants on wooden and porous substrates.
Primer for sealants on wooden and porous substrates.
Sitol® Deck Caulking S
Neutral, sandable silicone sealant for teak caulking.
Neutral, sandable silicone sealant for teak caulking.
Sitol® Deck Bonding
Hybrid polymer-based adhesive-sealant with extended open time for natural and…
Hybrid polymer-based adhesive-sealant with extended open time for natural and synthetic teak.
Sitol® Deck Caulking
Hybrid polymer-based, sandable sealant for teak caulking.
Hybrid polymer-based, sandable sealant for teak caulking.
Sitol® Marine
Fast hardening adhesive-sealant based on hybrid polymers with high initial…
Fast hardening adhesive-sealant based on hybrid polymers with high initial adhesion.
Details
Bitumen Seal is a ready-to-use, single-component, elastoplastic adhesive-sealant based on bitumen, inert fillers, resins, plasticisers, additives and solvents, specifically designed for bonding and sealing substrates of various types and natures.
Instructions for use
Instructions for use
- The supports and/or sides of the joint must be clean, degreased and sufficiently dry; any loose, crumbly or non-adherent parts, paint, rust, dust and release oils must be removed.
- Any old membranes with bulges can be incised in a cross pattern, then the four edges must be re-glued, first underneath and then on top over the entire surface.
- Insert the cartridge into the appropriate mechanical or pneumatic gun and extrude using nozzles with a diameter proportionate to the application in progress.
- When laying elements by gluing, apply beads of product to ensure sufficient coverage of the surface.
- In the case of joints, after applying adhesive tape along the sides of the joint, inject the sealant generously.
- Smooth with a damp spatula within 5 minutes of application, applying a certain amount of pressure to eliminate air pockets.
- Remove the adhesive tape immediately after smoothing.
Cleaning of tools
In the plastic state with solvents; after hardening, mechanically.
Storage
In its original sealed packaging, at a temperature not lower than +5 °C, away from heat sources and open flames, it can be stored for at least 24 months.
Warnings
- Do not use in unventilated areas or inside homes.
- Apply at temperatures between 0 °C and +35 °C; avoid extreme heat and cold conditions during application and drying of the film.
- Do not mix with cement or water.
| Color | Code | Packaging | Packaging size | Pallet | Barcode |
|---|---|---|---|---|---|
| Black | 8021 | cartridge | 12x280 ml |
72 cardboards
|
|
Given its ability to guarantee excellent adhesion on various types of substrates such as bituminous, cementitious, wood, metal, glass and plastic, it is suitable for bonding and/or repairing bitumen-polymer membranes and Canadian tiles, installing insulating panels, sealing joints, chimney pots, skylights, ventilators, antenna rods, sheet metal and flashings. It is compatible with subsequent waterproofing treatment of the membrane with Primer Aquatech and Aquatech.
| TEST PARAMETER AND METHOD | VALUE |
| Appearance | thick paste |
| Colour | black |
| Application temperature | from 0 °C to +35 °C |
| Dry residue at 130 °C (EN ISO 3251) | 85% – 95% |
| Brookfield viscosity at 25 °C (rev. no. 7 – 2 rpm) (EN ISO 3219) | 15.000 P ± 3.000 |
| Specific gravity at 20 °C (EN ISO 2811-1) | 1,40 kg/l |
| Closed cup flash point | > 30 °C |
| Slump test at 20°C after 5 minutes | max. 10 mm |
| Skin formation time at 23°C and 50% humidity | ca. 30 min. |
| 100% elastic modulus (DIN 53504), S3 die | 0,25 MPa |
| 100% elastic module (EN ISO 7339/A), M1up mortar backing | 0,0061 MPa |
The approximate consumption of the product as an adhesive is around 0.8 kg/m²; as a sealant, see the table below.
| INDICATIVE CONSUMPTION TABLE | ||
| JOINT WIDTH X DEPTH (MM) | CONSUMPTION PER LINEAR METRE | LINEAR METRES COVERED WITH ONE CARTRIDGE |
| 6×6 | 36 ml | 7,8 |
| 8×8 | 64 ml | 4,4 |
| 10×10 | 100 ml | 2,8 |
| 15×10 | 150 ml | 1,9 |
| 20×10 | 200 ml | 1,4 |
