Tile Epoxy
Two-component epoxy mortar, class R2 T in accordance with EN 12004 and RG in accordance with EN 13888, for bonding and grouting ceramic tiles, ceramic and glass mosaics, marble and natural stone up to a thickness of 15 mm.
Two-component epoxy mortar, class R2 T in accordance with EN 12004 and RG in accordance with EN 13888, for bonding and grouting ceramic tiles, ceramic and glass mosaics, marble and natural stone up to a thickness of 15 mm.
- Excellent workability and cleanability
- High chemical and mechanical resistance
- Perfect waterproofing
- Maximum colour stability
Variations
Choose the perfect solution for your project
White
Jasmin 1013
Bright grey 7047
Grey
Slate grey
Black 9005
Bahama 1001
Chestnut 8028
Application areas
Where Tile Epoxy performs best
Discover more
Other solutions you might be interested in
Details
Tile Epoxy is a two-component mortar based on epoxy resins, special quartz and specific additives, designed to create waterproof grout joints with high chemical resistance; it is characterised by excellent workability and is extremely easy to clean. It is resistant to freeze-thaw cycles.
Instructions for use
Preparation for installation
When using as an adhesive, ensure that the substrate – whether concrete, screed, plaster or other – is sufficiently cured and strong, clean and free from traces of dust or general dirt, oils or grease, and that it is not damp or wet.
Product preparation
Pour the pre-measured Component B into the Container for Component A and mix thoroughly until a homogeneous mixture is obtained.
Installation instructions
If used as an adhesive, apply the product by spreading it onto the substrate using a notched trowel, then lay the ceramic or stone tiles; or, when used as a joint filler, use a rubber squeegee, taking care to fill the joints thoroughly; then remove any excess. Once prepared, the mixture has a pot life of approximately 45 minutes; higher temperatures shorten the pot life, whilst lower temperatures extend it.
Cleaning
Proceed to clean the grouted joints by repeatedly wiping them with water – preferably lukewarm – and a stiff or abrasive sponge.
Final cleaning
Once the product has begun to set, it can be cleaned with water containing 10 per cent alcohol. Once fully set, only mechanical cleaning is possible.
Storage
24 months in the original packaging if stored in a cool, dry place at temperatures between +10 °C and +25 °C.
Warnings
Do not use Tile Epoxy:
- If there is water on the substrate.
- If the mixing ratios are incorrect and/or if it is thinned with water, other types of binders or solvents.
- At temperatures below +10 °C or above +25 °C.
- For grouting untreated terracotta tiles and/or on substrates that do not ensure adequate cleanability; in such cases, a preliminary test is recommended.
- For joints subject to movement; in such cases, use Torggler silicone sealants.
- In situations where the intended use involves contact with acids and strong oxidising agents; therefore, for all applications where the grout may come into contact with brass or copper profiles, edging, frames or substrates. In such cases, the material may deteriorate and change colour, which could also affect adjacent areas or those in close contact with the product itself.
- In situations where the intended use involves exposure to UV rays (please consult the Torggler technical service).
- Where different production batches are used, as these may exhibit slight colour variations.
| Color | Code | Components | Packaging | Packaging size | Pallet | Barcode |
|---|---|---|---|---|---|---|
| White | 15190 | 2 components | bucket | 3kg |
100 buckets
|
|
| Jasmin 1013 | 15191 * | 2 components | bucket | 3kg |
100 buckets
|
|
| Bright grey 7047 | 15196 | 2 components | bucket | 3kg |
100 buckets
|
|
| Grey | 15197 | 2 components | bucket | 3kg |
100 buckets
|
|
| Slate grey | 15536 * | 2 components | bucket | 3kg |
100 buckets
|
|
| Black 9005 | 15198 * | 2 components | bucket | 3kg |
100 buckets
|
|
| Bahama 1001 | 15193 * | 2 components | bucket | 3kg |
100 buckets
|
|
| Chestnut 8028 | 15194 * | 2 components | bucket | 3kg |
100 buckets
|
|
Adhesive for the installation and bonding of ceramic tiles, mosaics, marble and natural stone to walls and floors, where high performance is required. Waterproof grout with high aesthetic appeal and excellent chemical and mechanical resistance, for grouting installed elements in domestic, industrial and commercial settings, on both vertical and horizontal surfaces. Ideal for areas such as bathrooms, showers, kitchens, swimming pools, baths, saunas, spa facilities, garages, shops, warehouses and premises used for industrial processes.
| Name | Concentration % | Prolonged contact at 20 °C | Occasional contact at 20 °C |
| Type of agent: acids | |||
| Acetic | 2.5% | + | + |
| Acetic | 5% | +/- | + |
| Acetic | 10% | – | – |
| Hydrochloric | 37% | +/- | + |
| Chromic | 20% | – | – |
| Citric | 10% | – | – |
| Formic | 2.5% | + | + |
| Formic | 10% | – | – |
| Lactic | 2.5% | + | + |
| Lactic | 5% | +/- | + |
| Lactic | 10% | – | +/- |
| Nitric | 25% | +/- | + |
| Nitrate | 50% | – | – |
| Oleic | – | – | |
| Phosphoric | 50% | +/- | + |
| Phosphoric | 75% | – | – |
| Sulphuric | 1.5% | + | + |
| Sulphuric | 50% | +/- | + |
| Sulphuric | 98% | – | – |
| Tannic | 10% | +/- | + |
| Tartaric | 10% | + | + |
| Oxalic | 10% | + | + |
| Type of agent: alkalis and saturated solutions | |||
| Ammonia | 25% | + | + |
| Caustic soda | 50% | + | + |
| Caustic potash | 50% | + | + |
| Sodium hypochlorite: Active chlorine | 6.5 g/l | +/- | + |
| Sodium hypochlorite: Active chlorine | 162 g/l | – | – |
| Agent type: saturated solutions | |||
| Sodium hyposulphite | + | + | |
| Sodium chloride | + | + | |
| Calcium chloride | + | + | |
| Iron chloride | + | + | |
| Aluminium sulphate | + | + | |
| Sugar | + | + | |
| Hydrogen peroxide | 1% / 10% | + | + |
| Sodium bisulphite | + | + | |
| Sodium hyposulphite | + | + | |
| Agent type: oils and fuels | |||
| Petrol | + | + | |
| Crude oil | + | + | |
| Diesel | + | + | |
| Olive oil | + | + | |
| Agent type: solvents | |||
| Ethyl alcohol | + | + | |
| Acetone | – | – | |
| Ethylene glycol | + | + | |
| Glycerine | + | + | |
| Perchloroethylene | – | – | |
| Trichloroethane | – | – | |
| Trichloroethylene | – | – | |
| Methylene chloride | – | – | |
| Toluene | – | – | |
| Benzene | – | – | |
| Xylene | – | – | |
Key: + = excellent resistance, +/- = fair resistance, – = poor resistance
| PARAMETER | VALUE |
| Mixing ratio | Comp. A : Comp. B = 94 : 6 |
| Component A | |
| Consistency | paste-like |
| Density | 1.65 kg/l |
| Viscosity at 25 °C | Over 1,000,000 mPa·s |
| Dry residue | 100% |
| Component B | |
| Consistency | thick liquid |
| Density | 0.95 kg/l |
| Viscosity | approx. 500 mPa·s |
| Dry residue | 100% |
| PARAMETER | REQUIREMENTS | VALUE |
| Determined on fresh mix | ||
| Application temperature | from +10 °C to +25 °C | |
| Pot life (at 23 °C and 50 % RH) | approx. 45 minutes | |
| Testing on cured product |
||
| AS AN ADHESIVE IN ACCORDANCE WITH EN 12004 | ||
| Initial adhesion (in accordance with EN 12004-2 / 8.5.3.2) | > 2 N/mm² | 5.6 N/mm² |
| Adhesion after immersion in water (in accordance with EN 12004-2 / 8.5.3.3) | > 2 N/mm² | 7.4 N/mm² |
| Adhesion after thermal shock (in accordance with EN 12004-2 / 8.5.3.4) | > 2 N/mm² | 2.5 N/mm² |
| Open time (in accordance with EN 1346) | > 20 minutes | > 20 minutes |
| Limited slip value (in accordance with EN 1308) | < 0.5 mm | < 0.2 mm |
| AS A FILLER IN ACCORDANCE WITH EN 13888 | ||
| Abrasion resistance (in accordance with EN 12808-2) | < 250 mm³ | < 250 mm³ |
| Flexural strength (in accordance with EN 12808-3) | 30 N/mm² | > 30 N/mm² |
| Compressive strength (in accordance with EN 12808-3) | > 45 N/mm² | > 45 N/mm² |
| Capillary absorption after 240 minutes (in accordance with EN 12808-5) | < 0.1 g | < 0.1 g |
| Shrinkage (in accordance with EN 12808-4) | < 1.5 mm/m | < 1.5 mm/m |
| Walkability (at 23 °C) | approx. 24 hours | |
| Full cure (at 23 °C) | approx. 7 days | |
| Operating temperature | from -20 °C to +100 °C | |
| Consumption as an adhesive | 2.0 to 4.0 kg/m² | |
| Consumption as grout | from 0.1 to 5.1 kg/m² (see table) | |
Consumption may vary depending on the application, the type and size of the tiles, the evenness of the substrate and the width of the grout lines. As a guide, approx. 2.0–4.0 kg/m² when used as an adhesive. When used for grouting, product consumption typically ranges from approx. 0.1 to approx. 2.0 kg/m².
| TILE SIZE | JOINT WIDTH (in mm) | ||
| Dimensions (in mm) | 2 | 5 | 8 |
| 20 x 20 x 4 | 1.2 | 3.2 | 5.1 |
| 50 x 50 x 4 | 0.5 | 1.3 | 2.0 |
| 100 x 100 x 6 | 0.4 | 1.0 | 1.5 |
| 120 x 240 x 12 | 0.5 | 1.2 | 1.9 |
| 200 x 200 x 10 | 0.3 | 0.8 | 1.3 |
| 300 x 300 x 10 | 0.2 | 0.5 | 0.8 |
| 400 x 400 x 10 | 0.2 | 0.4 | 0.7 |
| 150 x 900 x 10 | 0.3 | 0.6 | 1.0 |
| 600 x 1200 x 10 | 0.1 | 0.2 | 0.3 |
The values in the table are expressed in kg/m².
Formula for calculating Tile Epoxy consumption
[(A+B)/(AxB)]xCxDx1.6 = consumption …….. kg/m²
Key: A = tile length, B = tile width, C = tile thickness, D = joint width
